SD300
POWER ELECTRONICS
24
DIMENSIONS
4. DIMENSIONS
IP20 Drives Dimensions
Frame 1N Dimensions
INPUT VOLTAGE
PHASES
EQUIPMENT
200~240[V]
3
SD300322
380~480[V]
3
SD300242
DIMENSIONS [mm/inch]
WEIGHT
(kg/lb)
W1
W2
H1
H2
H3
D1
A
B
Ø
68
(2.7”)
61.1
(2.4”)
128
(5”)
119
(4.7”)
5 (0,2”)
128
(4.8”)
3.5
(1,4”)
4 (0.2”)
4.2
(1.65’’)
0.86
(1.9lb)
Frame 1N dimensions
4
