Power Electronics SD300 Series User Manual

SD300
POWER ELECTRONICS
296
COMMONLY USED CONFIGURATIONS
Parameter
Default
value
Description
Set value
dr.15
0
Torque boost
0: Manual torque (Both directions can be
configured separately, in dr.16 ➔ ‘Start torque in
forward direction’ and in dr.17 ➔ ‘Start torque in
reverse direction’).
1 and 2: The drive automatically calculates the
voltage to apply at the start using the motor
parameters.
dr.18
60.00Hz
Motor frequency
50.00Hz
dr.19
0.50Hz
Start frequency
0.10Hz
dr.20
60.00Hz
Max speed limit
50.00Hz
dr.93
0
Parameter initialization
1: Set parameters back to their factory value (only
if required).
dr.97
2.x
Software version
-
Cn.4
3kHz
Modulation frequency
5kHz
In.1
50.00Hz
Analog input max. freq
50.00Hz
In.7
10
V1 filter
10ms (Low Pass Filter for V1).
In.8
0V
V1 minimum voltage
0.00V (V1 minimum voltage adjustment).
In.9
0.00
V1 minimum reference
0.00 (% of the value set in In.1)
In.10
10V
V1 maximum voltage
10.0V (V1 maximum voltage adjustment).
In.11
100.00
V1 maximum reference
100.00 (% of the value set in In.1)
In.52
10ms
I2 filter
10ms (Analogue input current filter).
In.53
4.00mA
I2 minimum current
4.00mA (I2 minimum current adjustment).
In.54
0.00
I2 minimum reference
0.00 (% of the value set In.1)
In.55
20.00mA
I2 maximum current
20.00mA (I2 maximum current adjustment)
In.56
100.00
I2 maximum reference
100.00 (% of the value set In.1)
In.65
1
Digital input 1
1: Forward start command
