POWER ELECTRONICS
MODBUS COMMUNICATION
229
Modbus Address
Parameter
Scale
Units
R/W
Data Values
Decimal
Hexadecimal
40014
0h000E
Drive Status
-
-
R
Bit 0: Stop
Bit 1: Start (+)
Bit 2: Start (-)
Bit 3: Fault
Bit 4: Accelerating
Bit 5: Decelerating
Bit 6: Steady Status
Bit 7: DC Brake
Bit 8: Stop
Bit 9: Fix Frequency
Bit 10: Open Brake
Bit 11: Start (+) Command
Bit 12: Start (-) Command
Bit 13: Start / Stop by
Communication
Bit 14: Freq. Reference by
Communication
Bit 15: 0-Remote; 1-Local
40015
0h000F
Fault information
-
-
R
Bit 0: Latch type fault
Bit 3: Level type fault
Bit 10: Hardware
diagnosis
40016
0h0010
Digital Inputs Status
-
-
R
Bit 0: P1
Bit 1: P2
Bit 2: P3
Bit 3: P4
Bit 4: P5
Bit 5: P6
Bit 6: P7
Bit 7: P8
40017
0h0011
Digital Outputs
Status
-
-
R
Bit 0: Relay 1
Bit 1: Multifunction output
40018
0h0012
V1
0.1
%
R
Voltage input V1
40019
0h0013
V2
0.1
%
R
Voltage Input V2 (Option
I/O)
40020
0h0014
I2
0.1
%
R
Current Input I2
40021
0h0015
RPM
1
rpm
R
Speed Output
40026
0h001A
Display unit
-
-
R
0: Hz
1: rpm
40027
0h001B
Number of poles
-
-
R
Motor poles visualization
