TECHNICAL CHARACTERISTICS
21
SD300 SERIES
PROTECTIVE
FUNCTION
Trip
Over current trip, External signal trip, ARM
short circuit current trip, Over heat trip, Input
imaging trip, Ground trip, Motor over heat trip,
I/O board link trip, No motor trip, Parameter
writing trip, Emergency stop trip, Command loss
trip, External memory error, CPU watchdog trip,
Motor normal load trip, Over voltage trip,
Temperature sensor trip, Drive over heat,
Option trip, Output imaging trip, Drive overload
trip, Fan trip, Pre-PID operation failure, External
break trip, Low voltage trip during operation,
Low voltage trip, Safety A(B) trip, Analog input
error, Motor overload trip.
Alarm
Command loss trip alarm, overload alarm,
normal load alarm, drive overload alarm, fan
operation alarm, resistance braking rate alarm,
number of corrections on rotor tuning error
Momentary Power Loss
HD below 15ms (ND below 8ms): Continuous
operation (To be within rated input voltage,
rated output) HD above 15ms (ND above 8ms):
Automatic restart operation enable
ENVIRONME
NT
Cooling Type
Forced fan cooling structure
Protection Degree
IP20/UL Open (Default), UL Enclosed Type 1
(Option), IP66/NEMA 4X (Option)
Ambient Temperature
IP20:
HD: -10~50˚C (14~122˚F)
ND: -10~40˚C (14~104˚F) [However, it is
recommended to use load below 80% when
using at 50°C under light load]
IP66:
HD: -10~40˚C (14~104˚F)
Storage Temperature
-20~65˚C (-4~149˚F)
Humidity
Relative humidity below 90% RH (no dew
formation)
Altitude, Vibration
Below 1,000m, below 9.8m/sec
2
(1G)
Location
No corrosive gas, flammable gas, oil mist and
dust etc. indoors (Pollution Degree 3
Environment)
Pressure
70~106 kPa
