Power Electronics SD300 Series User Manual

SD300
POWER ELECTRONICS
318
CONFIGURATION REGISTER
PARAMETER
DEFAULT
VALUE
SETTING 1
SETTING 2
dr.97
Software version
0
___________________
___________________
dr.98
IO Software version
0
___________________
___________________
dr.99
Hardware version
0
___________________
___________________
bA: Basic Functions
bA.1
Alt Speed Ref
None
___________________
___________________
bA.2
Aux calculation type
M+(G*A)
___________________
___________________
bA.3
Auxiliary reference gain
100.0%
___________________
___________________
bA.4
Control mode 2
REMOTE
___________________
___________________
bA.5
Speed reference source 2
LOCAL
___________________
___________________
bA.6
Alternative torque reference
LOCAL
___________________
___________________
bA.7
V/F Pattern
Linear
___________________
___________________
bA.8
Acceleration ramp type
MaxFreq
___________________
___________________
bA.9
Time scale
0.1s
___________________
___________________
bA.10
Input Frequency
60Hz
___________________
___________________
bA.11
Pole Number
4
___________________
___________________
bA.12
Rated Slip
40rpm
___________________
___________________
bA.13
Motor Current
3.6A
___________________
___________________
bA.14
No load Current
1.6A
___________________
___________________
bA.15
Motor Voltage
0V
___________________
___________________
bA.16
Efficiency
72%
___________________
___________________
