Power Electronics SD300 Series User Manual

SD300
POWER ELECTRONICS
322
CONFIGURATION REGISTER
PARAMETER
DEFAULT
VALUE
SETTING 1
SETTING 2
Ad.17
Frequency start DC brake
5.00Hz
___________________
___________________
Ad.20
Acceleration dwell frequency
5.00Hz
___________________
___________________
Ad.21
Acceleration dwell time
0.0s
___________________
___________________
Ad.22
Deceleration dwell frequency
5.00Hz
___________________
___________________
Ad.23
Deceleration dwell time
0.0s
___________________
___________________
Ad.24
Use frequency limit
N
___________________
___________________
Ad.25
Frequency lower limit
0.50Hz
___________________
___________________
Ad.26
Frequency higher limit
[]/dr.20Hz
___________________
___________________
Ad.27
Jump frequency activation
N
___________________
___________________
Ad.28
Lower limit jump frequency 1
10.00Hz
___________________
___________________
Ad.29
Upper limit jump frequency 1
15.00Hz
___________________
___________________
Ad.30
Lower limit jump frequency 2
20.00Hz
___________________
___________________
Ad.31
Upper limit jump frequency 2
25.00Hz
___________________
___________________
Ad.32
Lower limit jump frequency 3
30.00Hz
___________________
___________________
Ad.33
Upper limit jump frequency 3
35.00Hz
___________________
___________________
Ad.41
Open brake current
50.0%
___________________
___________________
Ad.42
Delay before brake opening
1.00s
___________________
___________________
Ad.44
Brake opening forward freq.
1.00Hz
___________________
___________________
Ad.45
Brake opening reverse freq.
1.00Hz
___________________
___________________
Ad.46
Delay before brake closing
1.00s
___________________
___________________
