Power Electronics SD300 Series User Manual

POWER ELECTRONICS
SD300
CONFIGURATION REGISTER
329
PARAMETER
DEFAULT
VALUE
SETTING 1
SETTING 2
In.15
V1 maximum negative
reference
-10.00%
___________________
___________________
In.16
V2 Inverting
N
___________________
___________________
In.17
Adjust V1 quantification
0.04%
___________________
___________________
In.35
V2 Monitor
0.00V
___________________
___________________
In.37
V2 filter
10ms
___________________
___________________
In.38
V2 minimum voltage
0.00V
___________________
___________________
In.39
V2 minimum reference
0.00%
___________________
___________________
In.40
V2 maximum current
10.00V
___________________
___________________
In.41
V2 maximum reference
100.00%
___________________
___________________
In.46
V2 Inverting
N
___________________
___________________
In.47
Adjust I2 visualization
0.04%
___________________
___________________
In.50
I2 Monitor
0.00mA
___________________
___________________
In.52
I2 filter
10ms
___________________
___________________
In.53
I2 minimum current
4.00mA
___________________
___________________
In.54
I2 minimum reference
0.00%
___________________
___________________
In.55
I2 maximum current
10.00mA
___________________
___________________
In.56
I2 maximum reference
100.00%
___________________
___________________
In.61
I2 Inverting
N
___________________
___________________
In.62
Adjust I2 visualization
0.04%
___________________
___________________
In.65
Digital input 1
1
___________________
___________________
