Power Electronics SD300 Series User Manual

POWER ELECTRONICS
SD300
CONFIGURATION REGISTER
331
PARAMETER
DEFAULT
VALUE
SETTING 1
SETTING 2
OU.2
Analog output 1 gain
100.0%
___________________
___________________
OU.3
Analog output 1 offset
0.0%
___________________
___________________
OU.4
Analog output 1 filter
5ms
___________________
___________________
OU.5
Analog output 1 constant
setting
0.0%
___________________
___________________
OU.6
Analog output 1 monitor
0.0%
___________________
___________________
OU.30
Relay fault output
010
___________________
___________________
OU.31
Relay 1 control source
Trip
___________________
___________________
OU.33
Digital output 1 function
Run
___________________
___________________
OU.41
Digital outputs status
00
___________________
___________________
OU.50
Digital output connection delay
0.00s
___________________
___________________
OU.51
Digital output disconnection
delay
0.00s
___________________
___________________
OU.52
NC/NO Relays logic
00
___________________
___________________
OU.53
Digital output connection delay
on fault
0.00s
___________________
___________________
OU.54
Digital output disconnection
delay on fault
0.00s
___________________
___________________
OU.55
Digital output connection delay
0.00s
___________________
___________________
OU.56
Digital output disconnection
delay
0.00s
___________________
___________________
OU.57
Relay FDT level
30.00Hz
___________________
___________________
OU.58
Relay FDT band
10.00Hz
___________________
___________________
OU.61
Pulse output mode
Frequency
___________________
___________________
