CONFIGURATION REGISTER
PARAMETER
DEFAULT
VALUE
SETTING 1
SETTING 2
M2.15
Motor 2 efficiency
___%
___________________
___________________
M2.16
Motor 2 inertia rate
__
___________________
___________________
M2.17
Stator resistor
___mΩ
___________________
___________________
M2.18
Leak inductor
_.___m
___________________
___________________
M2.19
Stator inductor
__.__mH
___________________
___________________
M2.20
Rotor time constant
___ms
___________________
___________________
M2.25
V/F pattern
Linear
___________________
___________________
M2.26
Torque in forward direction
+2.0%
___________________
___________________
M2.27
Torque in reverse direction
+2.0%
___________________
___________________
M2.28
Stall prevention level motor 2
150%
___________________
___________________
M2.29
Motor 2 overcurrent level
during 1 minute
+150%
___________________
___________________
M2.30
Motor 2 continuous
overcurrent level
+100%
___________________
___________________
US: PLC Sequence
US.1
PLC operation mode
Stop
___________________
___________________
US.2
PLC loop time
0.02s
___________________
___________________
US.11
Output link address for PLC
function 1
0
___________________
___________________
US.12
Output link address for PLC
function 2
0
___________________
___________________
US.13
Output link address for PLC
function 3
0
___________________
___________________
US.14
Output link address for PLC
function 4
0
___________________
___________________
