CONFIGURATION REGISTER
343
PARAMETER
DEFAULT
VALUE
SETTING 1
SETTING 2
US.54
PLC input value 24
0
___________________
___________________
US.55
PLC input value 25
0
___________________
___________________
US.56
PLC input value 26
0
___________________
___________________
US.57
PLC input value 27
0
___________________
___________________
US.58
PLC input value 28
0
___________________
___________________
US.59
PLC input value 29
0
___________________
___________________
US.60
PLC input value 30
0
___________________
___________________
US.80
Analogue input V1 value
0.000
___________________
___________________
US.81
Analogue input I2 value
+0.000
___________________
___________________
US.82
Digital inputs value
0
___________________
___________________
US.85
Analogue output value
-
___________________
___________________
US.88
Digital output value
0
___________________
___________________
UF: PLC Function
UF.1
PLC function 1
NOP
___________________
___________________
UF.2
Input A PLC function 1
0
___________________
___________________
UF.3
Input B PLC function1
0
___________________
___________________
UF.4
Input C PLC function1
0
___________________
___________________
UF.5
Output PLC function 1 PLC
+0
___________________
___________________
UF.6
PLC function 2
NOP
___________________
___________________
UF.7
Input A PLC function 2
0
___________________
___________________
