Power Electronics SD300 Series - Page 38

SD300
POWER ELECTRONICS
36
DIMENSIONS
Frame 2I Dimensions
INPUT VOLTAGE
PHASES
EQUIPMENT
200~240[V]
3
SD300826, SD301126,
SD301726
380~480[V]
3
SD300446F, SD300646F,
SD300946F
DIMENSIONS [mm/inch]
WEIGHT
(kg/lb)
W1
W2
H1
H2
H3
D1
D2
A
Ø
T1
T2
220
(8.7”)
204
(8”)
259
(10”)
241
(9.5”)
12
(0.5”)
201
(7.9”)
215
(8.5”)
5.5
(0.2”)
5.5
(0.2”)
22.3
(0.9”)
28.6
(1.1”)
5.3 (12lb)
Frame 2I dimensions
