Power Electronics SD300 Series - Page 50

SD300
POWER ELECTRONICS
48
MECHANICAL INSTALLATION
• Air Flow: 4 Frame.
4 Frame
5,5/7,5kW-2
5,5/7,5kW-4
Air flow
Max Air Flow [m3/min]
0,98 (34,6 CFM)
• Air Flow: 5 Frame.
5 Frame
11kW-2
11/15kW-4
Air Flow [m3/min]
Min.
1,45
Rated
1,55
• Air Flow: 6 Frame.
6 Frame
15kW-2
18,5/22kW-4
Air Flow [m3/min]
Min.
2,85
Rated
3,15
