USE OF THE DISPLAY
91
KEY / LED
NAME
FUNCTION
DOWN key
Used both to scroll down through the parameters of a group
and to decrease a parameter value.
Left key
Used to jump to other parameter groups or move the cursor
to the left.
Right key
Used to jump to other parameter groups or move the cursor
to the right.
Enter key
Used to set a parameter value or to save the changed
parameter value.
Escape key
Used to cancel the changes or to switch from Remote/Local
if this option was previously configured.
FWD LED
Forward Run
Illuminated during forward run.
LEDS flicker when a fault occurs.
REV LED
Reverse Run
Illuminated during reverse run.
RUN LED
Run
Illuminated during operation / Flickering during
acceleration/deceleration.
SET LED
Setting
Illuminated during parameter setting / Flickering when the
ESC key is operating as a multi-key.
Seven-segment
display
Current value
Indicates operating conditions and parameter data.
