VAC4 and VAC4S Hardware User’s Guide
085-00000700 Rev K
support@powerfleet.com
Page 27 of 103
L
DB firmware upgrade status
0-0
No firmware to download or install
0-1
Firmware install pending
1-0
Firmware downloading
2-0
Firmware pending download
3-1
Fully downloaded, pending installation
S
Overall firmware upgrade state
A9,B9,E9,F9
VAC can program available firmware
00,02,08,10,12,18,20,22,28,30,32,38,40,
42,48,50,52,58,60,62,68,70,72,78,80,
82,88,90,92,98,1A,2A,3A,4A,5A,6A,
7A,8A,9A,0A,A0,A2,A8,AA,B0,B2,B8,
BA,C0,C2,C8,CA,D0,D2,D8,DA,E0,E2, E8,EA,F0,F2,F8,FA
VAC can only program available firmware by a
request from an authorized operator
09,19,29,39,49,59,69,79,89,99,C9,D9
VAC can only program available DB firmware
03,13,23,33,43,53,63,73,83,93,1B,2B,3B,
4B,5B,6B,7B,8B,9B,A3,AB,B,B3,BB,C3, CB,D3,DB,E3,EB,F3,FB
VAC cannot program any firmware because
VAC is in ID Optional mode
P
(1st 2 digits): PIB firmware upgrade status
0-0
No firmware to download or install
0-1
Firmware install pending
1-0
Firmware downloading
2-0
Firmware pending download
3-1
Fully downloaded, pending installation
P
(2nd 2 digits): Firmware upgrade priority
00, 02, 10, 12
PIB is currently highest priority
01, 03
DB is currently highest priority
11
SH is currently highest priority
Note: Other combinations are possible, contact PowerFleet Support for more details.
