Understand and Manually Set “Motion” for Electric Vehicles
(Not applicable for JPT, P-Plug and VDI cable installations)
The VAC installation and configuration wizard is always used for establishing motion and idle thresholds on a vehicle. In
some cases, motion and idle values may need to be adjusted during troubleshooting. One reason may be that the vehicle
will not pass the initial configuration wizard. Another reason may be that motion diagnostic errors appear regularly.
The VAC determines the state of the vehicle (idle or motion) by configuring two ‘idle’ ranges based on voltage sampling
of the “BLU” wire connection. The sampling methods (the numbers displayed) are different depending on the Vehicle
Type (e.g. Elec avg, Elec min/max). The two idle ranges will typically differ when the “BLU” connection voltage changes
between key-on and key-off while the motor is disengaged. In other scenarios, the two idle ranges may be identical.
1. Log into the vehicle.
2. On the first menu screen, select HARDWARE.
3. Scroll down to the second page of the menu screen.
4. On the “Hardware” sub-menu, select MOTION.
Select EDIT which opens a new screen where you can type in the required values between 0 and 1023 (center point)
and between 0 and 255 (range). This method is a last resort and would be used in a trial-and-error scenario with
assistance from PowerFleet Support.
