The activity definition is on the following page.
Item
Description
Values
Mtn
Motion meter; same as Mtn1 or a combination of Mtn1 and Mtn2.
0, 1, or X
Eng
Engine-on meter; used for internal combustion vehicles only (BRN wire)
0, 1, or X
Act
Activity meter as assigned during the VAC install Sensor wizard.
0, 1, or X
Mtn1
Motion meter; BLU wire (electric), Eng+Gear (internal combustion)
0, 1, or X
Mtn2
Not currently available
X
Gear
In gear; used for internal combustion vehicles only (BLU wire)
0, 1, or X
Slep
Sleeper mode; Seat = 1 but Mtn, Mtn1, Mtn2, Sped, Act, and Lift = 0 or X
0, 1, or X
Seat
Seat or dead-man meter (PUR wire)
0, 1, or X
Brak
Parking brake interface; prevents operator logoff unless brake is applied
0, 1, or X
Lift
Lift motor meter
0, 1, or X
Gau1
Vehicle gauge (or indicator); typically, high engine temperature
0, 1, or X
Gau2
Vehicle gauge (or indicator); typically, low oil pressure
0, 1, or X
Batt
Vehicle battery voltage
000.0V
Sped
Current vehicle speed (based on odometer or GPS)
0 – 99.9 mph
LftW
Load meter (motion with load, travel with load, etc.)
0, 1, or X
DlyT
Tow meter
0, 1, or X
Batt
Current vehicle battery voltage (B+ wire)
0 – 99.9 volts
Im X, Y, P
Current impact sensor X-axis, Y-axis, and duration thresholds
0 – 255
Creeper
CAN/Serial mode that activates unsafe mode
0, 1, or X
Speed
When unsafe mode is active, shows if drive speed is limited in unsafe mode
0, 1, or X
Lift1
When unsafe mode is active, shows if lift speed is limited in unsafe mode
0, 1, or X
TEMP
Last recorded, Average recorded readings for VAC internal temperature (in C)
C
BLU
Active/Inactive - Last recorded - Avg values for Mtn1 (electric), Gear (IC)
0-00000-00000
PUR
Active/Inactive - Last recorded - Average recorded values for Seat
0-00000-00000
BRN
Active/Inactive - Last recorded - Avg values for Mtn1 (electric), Eng (IC)
0-00000-00000
RED
Active/Inactive - Last recorded - Avg recorded values for Batt
0-00000-00000
TMP
Active/Inactive - Last recorded - Avg recorded values for internal VAC
temperature (in C x 10; 315 = 31.5)
0-00000-00000
VBN
Active/Inactive - Last recorded - Avg recorded values for Mtn2 (electric, IC)
0-00000-00000
Activity
Determines activity, if wake is enabled and calculates activity wake modules
00000-00-00
0 = currently inactive, 1 = currently active, X = feature disabled
Note: See the following table for most common Activity assignments. Additional combinations are possible, contact
PowerFleet’s Support if the value displayed is not shown).
