VAC4 and VAC4S Hardware User’s Guide
The items and description are as follows:
Status of the BASIC configuration wizard
Vehicle ID entered during the BASIC wizard
Vehicle type selected during the BASIC wizard
Determines whether the VAC is configured for wired and OEM plug inputs (Y)
or wired or OEM plug (N)
Facility ID entered as well as facility code name (if sync’d with software)
VAC serial number (excluding manufacturing site and product type)
Motion (BLU wire; electric vehicles) “inactive” 1st set point and range
Motion (BLU wire; electric vehicles) “inactive” 2nd set point and range
Engine On (BRN wire; GAS/IC vehicles) “inactive” 1st set point and range
Engine On (BRN wire; GAS/IC vehicles) “inactive” 2nd set point and range
Motion (BLU wire; GAS/IC vehicles) “inactive” 1
st
set point and range
Motion (BLU wire; GAS/IC vehicles) “inactive” 2nd set point and range
Lift motor (BRN wire; electric vehicles) “inactive” 1st set point and range
Lift motor (BRN wire; electric vehicles) “inactive” 2nd set point and range
Seat or deadman switch (PUR wire) “inactive” 1st set point and range
Seat or deadman switch (PUR wire) “inactive” 2nd set point and range
Gauge 1 (VIM10) “inactive” 1st set point and range
Gauge 1 (VIM10) “inactive” 2nd set point and range
Gauge 2 (VIM11) “inactive” 1st set point and range
Gauge 2 (VIM11) “inactive” 2nd set point and range
Battery change confirmation configuration
Output Alert (VIM7) “inactive” set point and range
Parking Brake (VIM8) “inactive” set point and range
Fork load sensor configuration
Configured,
Not Configured
Tow sensor (VIM5) “inactive” set point and range
State of access control relay
Information IDSY Support may request to troubleshoot install issues
GPS sensor (C102 or VIM1) configuration
Impact sensor configuration
SSSS = set point value, RRR = range value, Y = yes, N = no
