2 Your balance
2.1 Construction and functions
2.1.1 Construction of the balance
The balance consists of the balance body (1), the scale-pan holder (4)
and the pan (5), which depending on the model may be square (fig.
2.1, right) or round (fig. 2.1, left).
Depending on the model (see Chapter 2.3 “Data and parameters”) the
balance additionally has a small (fig. 2.1, right) or large (fig. 2.1, left)
windshield (2) and/or a protective ring (3).
Fig. 2.1 Your balance
2.1.2 Functions of the balance
The balances of the XT-Series are high-quality electronic precision ba-
lances with a readability of 0.0001 grammes to 1.0 gramme,
according to type.
1
2
4
3
4
5
2
3
1
