Precisa Series XT - Password protection of the menus

4 Modes of operation and operating ■
27
4.5.4 Display
The balance display has two lines (1 and 2).
Fig. 4.2 Display
The upper display-line (1) includes the 8-figure measurement display
(3) as well as various symbols (4).
The lower line (2) serves as a 20-character info-line in connection with
the cursor keys for controlling the working programs.
4.5.5 Info-line and function keys
If an application (a working-program) is employed, the four-column
info-line (2) will also appear at the lower margin of the display in ad-
dition to the measurement display (1).
Each of the functions indicated in the info-line corresponds to the
function key lying directly below it (marked with a G (3)).
Fig. 4.3 Info-line and function keys
B/G
PT
NET
2
34
1
PRINT
MENU
ON/OFF
TT
ins
esc
clr
PRINT
MENU
ON/OFF
TT
ins
esc
clr
B/G
PT
NET
2
1
3
4
