For data-transfers to peripheral devices, the balance is equipped with
an RS232/V24-interface.
Before the data-transfer, the RS232 interface must be matched with
the one in the peripheral device in the balance's configuration menu
(see Chapter 5.8 “Interface-functions”).
• Handshake
The handshake is set to “NO” (none) in the works. It can be set to
software handshake XON/XOFF, or to hardware handshake.
• Baud rate
Possible baud rates: 300, 600, 1200, 2400, 4800, 9600 or
19200 baud.
• Parity
Possible parity: 7 even 1 stop, 7 odd 1 stop, 7 No 2 stop or
8 No 1 stop.
ParitySB12345678SP
7-even-1 SB 1.DA 2.DA 3.DA 4.DA 5.DA 6.DA 7.DA PB SP
7-odd-1 SB 1.DA 2.DA 3.DA 4.DA 5.DA 6.DA 7.DA PB SP
7-no-2 SB 1.DA 2.DA 3.DA 4.DA 5.DA 6.DA 7.DA 1.SP 2.SP
8-no-1 SB 1.DA 2.DA 3.DA 4.DA 5.DA 6.DA 7.DA 8.DA SP
SB: Start bit PB: Parity bit
DA: Data bit SP: Stop bit
