menu: Service menu (51765761) > Settings > System Settings > System Tests.
Machine diagnostics tests to verify system hardware operation.
SYSTEM TESTS
MENU
TEST DESCRIPTION
AMT Stride Pos-
ition Test
(AMT only)
menu: System Tests >AMT Stride Position Test
Verifies the stride movement:
l Low Radius.
l HiRadius.
l Dynamic Position.
Brake Test menu: System Tests >Brake Test
If the brake is operational, provides the following operating information:
l PWRB XXX: The current power bits.
l RPM: Brake generator RPM.
l VBUS XX: Bus Voltage used to drive the brake.
l M-AMPS XX: DC brake current.
Battery Test menu: System Tests >Battery Test
Shows the current battery voltage level as "XX.X VDC Y".
Where:
XX.X is the measured DC battery voltage (nominal 12.6 - 14.6 Vdc).
There can be an additional "Y" suffix indicating the following condition:
"C" an external AC charger is connected.
"L" the battery is low (less than 11.5 Vdc).
"CL" charger is connected and the battery is low.
RPM Test menu: System Tests >RPM Test
RPM test:
l Pulse: current pulse count.
l Minimum: minimum pulse count.
l Maximum: maximum pulse count.
SPM Test menu: System Tests >SPM Test
(EFX, AMT only)
SPM "Strides per Minute" test:
l Pulse: current pulse count.
l Minimum: minimum pulse count.
l Maximum: maximum pulse count.
CrossRamp Test menu: System Tests >CrossRamp Test
(EFX, AMT only)
Manually run the lift motor to raise/lower the crossramp through full
P82 Console 58
7 Standard Service Menus
Service Menu (51765761)
