Preen AFV-P-5000 - Calibration Options (Voltage)

AFV-P Series High Performance Programmable AC Power Supply
95
Figure 6.3 CALIBRATION pages 1 & 2
Figure 6.4 CALIBRATION page 3
The description for the items at the CALIBRATION page are given as follows,
1) : Press to enter into the page which calibrates the
HI-Range voltage 310V.
2) : Press to enter into the page which calibrates the
LO-Range voltage 155V.
3) : Press to enter into the page which calibrates the
HI-Range voltage 60V.
4) : Press to enter into the page which calibrates the
LO-Range voltage 60V.
5) : Press to enter into the page which calibrates the
HI-Range RMS current.
