AFV-P Series High Performance Programmable AC Power Supply
27
3.4 MENU Page
If the MAIN page is shown on the touch screen, users can press the icon to
enter into the MENU page. Please see the following figures,
Figure 3.7 MENU page 1 Figure 3.8 MENU page 2
The description for the icons at the MENU page is given as follows:
1) : Press to enter into the SETTINGS page.
2) : Press to enter into the PROGRAMMABLE page.
3) : Press to enter into the COMMUNICATION page.
4) : Press to enter into the RESULTS page.
5) : Press to enter into the WAVE page.
6) : Press to enter into the METER page.
7) : Press to enter into the INFORMATION page.
8) : Press to return to the MAIN page.
9) : Press to return to the previous page.
10) : Press to move to the previous page of the MENU page.
11) : Press to move to the next page of the MENU page.
