AFV-P Series High Performance Programmable AC Power Supply
68
4 Basic Mode: MEMORY feature
The product supports MEMORY feature on BASIC mode to memorize multiple output
settings. Up to 50 Memory Sets can be stored, and the name of each Memory Set is
editable to call for test sequence. There are 4 shortcuts of Memory Sets for quick
switching at output page, including the first three Memory Sets and one selectable
from the 50 sets.
If the MENU page is shown on the touch screen, user can press the icon to
enter into the MEMORY page. Please see the following figure:
Figure 4.1 MEMORY page
The description for the items and the icons at the MEMORY subpage are given as
follows:
1) ：Press to set the name, voltage and frequency
of the Memory Set, and the settings will show on the item.
2) ：Show the name of Memory Set with the default name "MEMORY
AC". The name can be edited within 10 characters.
3) : Show the output voltage of the Memory Set.
4) : Show the output frequency of the Memory Set.
5) : Press to switch pages. 5 Memory Sets in one page, there are 50 sets
in total.
