AFV-P Series High Performance Programmable AC Power Supply
4
Voltage Resolution
0.1V
Frequency Range
15-1000Hz
Frequency Accuracy
0.1Hz at 40-500Hz;
0.2Hz at 501-1000Hz
Frequency Resolution
0.1Hz
Current Range
Hi: 1-12A/
Lo: 0.005-1.2A
Hi: 2-24A/
Lo: 0.005-2.4A
Hi: 0.05-48A
Current Accuracy
(1% of Reading + 5 Counts), at 40-500Hz;
(1% of Reading + 10 Counts), at 501-1000Hz
Current Resolution
Hi: 0.01A / Lo: 0.001A
Hi: 0.01A
Peak Current Range
0-45A
0-90A
0-180A
Peak Current Accuracy
(1% of Reading + 5 Counts), at 40-500Hz;
(1% of Reading + 10 Counts), at 501-1000Hz
(1% of Reading
+ 5 Counts)
Peak Current Resolution
0.1A
Power Range
Hi: 100-1200W/
Lo: 0-120W
Hi: 200-2400W/
Lo: 0-240W
Hi: 0-4800W
Power Accuracy
(2% of Reading + 10 Counts), at 40-500Hz;
(2% of Reading + 15 Counts), at 501-1000Hz
Power Resolution
Hi: 1W/Lo: 0.1W
Hi: 1W
General
Efficiency
77% at Max. Power
80% at Max. Power
Protection
OVP, UVP, OCP, LVP, OPP, OTP, RCP, Fan Fail and AMP Fail
Remote Interface
Standard: RS232/RS485/Ethernet/USB/PLC Remote In & Out;
Option: GPIB/Analog Control
Over Current Foldback
(OC-FOLD)
When the OC-FOLD mode is enabled, the criteria to activate/deactivate the OC-FOLD
mode is the set value of the max. output current. The response time from exceeding
the up limit to falling back to the up limit is 1.4S.
Synchronized Signal
ON, Event for Voltage or Frequency Change (Output signal 5V, BNC type)
Memories
50 Memory Sets & 1200 Steps (24 Steps/Memory Set)
Operating Temperature
0-40C
Dimensions(H×W×D)
88 x 442 x 495mm
88 x 442 x 650mm
176 × 442 × 665mm
3.5 x 17.4 x 19.5inch
3.5 x 17.4 x 25.6inch
6.9 x 17.4 x 26.2inch
Weight
16kg
20kg
31.3kg
61.5kg
35.3lbs
44.1lbs
69lbs
135.6lbs
All specifications are subject to change without notice
Table 1.1 Technical specifications
