AFV-P Series High Performance Programmable AC Power Supply
104
NOTICE
The definition of the suitable load for calibrating the peak current are given as
follows, and the suitable load shall be resistive load.
Model
Resistive Value
Rated Power
AFV-P-600
20Ω
500W
AFV-P-1250
10Ω
1000W
AFV-P-2500
5Ω
2000W
AFV-P-5000
2.5Ω
4000W
Figure 6.17 Enter into the page which calibrates the peak current
Figure 6.18 Enable the calibration of the peak current
