AFV-P Series High Performance Programmable AC Power Supply
8
Item
Name
Description
5
AC Output Socket
This socket is used to output AC power to the load.
6
Output Terminals
These terminals can output AC & DC power to the load.
7
Remote Sense Connector
This connector senses directly at the terminals of the load to
compensate any voltage drop on the connecting cable.
NOTICE: Make sure to connect the terminal “S
L
” of the remote
sense connector to the terminal “L” of the load, and connect
the terminal “S
N
” of the remote sense connector to the ter-
minal “N” of the load. Notice that reverse polarity is not al-
lowed.
8
USB Interface
This interface is used for remote control via the USB cable.
9
RS232/RS485 Interface
This interface is used for remote control via the RS232/RS485
cable
10
Ethernet Interface
This interface is used for remote control via the Ethernet ca-
ble.
11
Input Voltage Selector
Verify this selector is switching to the position (either 115V or
230V) matching the input voltage.
NOTICE: This selector is specialized for the product models of
AFV-P-600 and AFV-P-1250.
12
PLC Remote In & Out
These interfaces are used for remote control via the PLC pro-
gramming cable.
13
USB Interface
The interface is used for firmware update via the USB cable.
14
Synchronized Signal I/O
This I/O is used to output synchronized signal via the BNC ca-
ble.
15
Input Terminals
(AC Inlet)
These terminals are used to connect the product with the
power line input.
NOTICE: These terminals are replaced by the AC inlet for the
product model of AFV-P-600.
