Other Features 5-35
PA-1628Operator's ManualH3-45 COACH
Enclosure Travelling frame housing that is rigidly attached to vehicle chassis.
Fluid reservoir Container holds hydraulic fluid that is used by hydraulic system.
Folding handrail (left and right) Provides a handhold for standing passenger (standee).
Front rollstop
Front barrier prevents wheelchair from inadvertently rolling off platform during platform
movement.
Handrail release button
(left and right) Locks handrail in vertical position. Must be pushed inward to release
handrail.
Hydraulic cylinder
Located within carriage and connected to lifting frame. Receives pressurized fluid from
hydraulic pump to lift platform.
Hydraulic pump
assembly
Electro-hydraulic unit provides hydraulic pressure used to raise platform. Also mounts
components for manual operation.
Lifting frame
Assembly is hinged to front of carriage and to center of platform; raised by single
hydraulic cylinder attached to carriage.
Manual pump handle
Used to manually operate hydraulic backup pump and pressure release valve when
electrical power is not available. Also used to rotate platform release shafts.
Platform
Curbed area where passenger resides while being raised to vehicle or lowered to
ground.
Platform release shaft
(left and right) Used during manual operation of lift. Disengages platform from
enclosure to facilitate manual deployment. Engage and rotate either shaft with manual
pump handle.
Pull box
Houses electrical termination points to lift, and a hydraulic line disconnect point. Also
accepts input harness from control pendant.
Rollstop control knob Provides manual control of rollstop if electrical power is not available.
Safety belt
Safety restraint belt that spans between handrails to help confine passenger to
platform area.
Stow Lock
Safety lock retains platform when in stowed position (retracted); releases when stow
lock lever is raised.
Traveling frame (not shown as unit) Assembly comprised of carriage, lifting frame, and platform.
