8-18 Care and Maintenance
PA-1628Operator's ManualH3-45 COACH
EXTERIOR LIGHTING VERIFICATION WITH
TEST MODE
This useful function allows quick verification of the
vehicle exterior lights.
Activating The Test Mode:
When the vehicle is stationary (parking brake
applied), pull up the multi- function lever 3 times
within 3 seconds to activate the test mode. This test
can be done when the engine is not running providing
that the battery charge is sufficient (above 24.0
volts).
The telltale panel alarm emits a sound each second
to remind that the test mode is in progress.
NOTE
Lighting test mode can also be initiated and
stopped using the DID menu “Exterior Lamp
Inspection”. For more information, refer to
"DRIVER INFORMATION DISPLAY" on page39
in Section 5 Other Features.
Stopping The Test Mode:
To stop the test mode, pull up the multi-function lever
once or turn the ignition OFF or remove the parking
brake.
NOTE
The test mode is useful to check the operation of
the multiplex outputs and the exterior lights. It
doesn't test the functionality of the commands
related to the exterior lighting. For a complete
testing, the directional signal commands, the
headlights commands and the brake pedal have to
be checked before. Once these commands tested,
activate the test mode to check the exterior
lighting.
Using The Test Mode:
First, test the functionality of the commands related
to the exterior lighting:
l Activate the right directional signal and check
that the corresponding cluster telltale light
illuminates.
l Activate the left directional signal and check
that the corresponding cluster telltale light
illuminates.
l Activate the hazard warning flashers and
check that the corresponding cluster telltale
lights illuminate.
l Press the headlights rocker switch in first
position and confirm that the instrument panel
illuminates. Press the headlights rocker
switch in second position and confirm that the
headlights illuminate.
l Turn on the high beams and check that the
corresponding cluster telltale light illuminates.
l Press onthe brake pedal and check that the
STOP telletal light illuminates
Once these commands tested, activate the test
mode to check the exterior lighting by pulling up the
multi-function lever 3 times within 3 seconds.
Go to the front of the vehicle and check the lights:
l Left and right directional signals.
l Identification lights and clearance lights.
l Low beams.
l High beams.
Left side and right side of the vehicle:
l Directional signals.
l Marker lights.
Rear of the vehicle:
l Directional signals.
l Identification lights and clearance lights.
l Stoplights and tail lights.
l Back-up light.
l Center High mounted Stop Light (CHSL)
