2-16 Coach Exterior
PA-1628 Operator's Manual H3-45 COACH
FIGURE 28: BATTERY CHARGER 120-VOLT
CONNECTOR – H3
HUBODOMETER
An odometer is installed on the curbside drive axle
wheel hub. The odometer calculates the total
distance in miles or kilometers (depending on the
model installed) traveled by the coach since
manufacture, including factory road testing.
NOTE
It is normal for the hubodometer, the engine
ECM and the vehicle odometer to disagree on
the total mileage.
FIGURE 29: HUBODOMETER
TRAILER HITCH
Your vehicle may be equipped with a factory-
installed trailer hitch which has been designed to
meet the following rating:
Maximum gross trailer weight:
20,000 lbs. (9072 kg)
Maximum tongue weight at 6 1/2 inches
(165mm) or less from coupling receiver:
1,500 lbs. (680 kg)
FIGURE 30: TRAILER HITCH
DANGER
The draw bar and the ball used for towing the trailer
should be rated for 20,000 lbs. capacity or more.
WARNING
Pulling a trailer weighing more than the
recommended maximum gross weight may cause
engine and transmission overheating, and a
possible hitch failure.
NOTE
Pulling a trailer over long distances is considered
as a "severe operating condition" for the vehicle.
The engine will require more frequent servicing.
TRAILER HITCH LOAD
The minimum requirement for a trailer weighing up
to 20,000 lbs. when coupled to a 20,000 lbs.
Prevost Trailer Hitch is as per the following:
1. Trailer must comply with Federal Motor
Carrier Safety Regulations 393.52
regarding trailer braking capability.
