Coach interior 3-7
PA-1628Operator's ManualH3-45 COACH
ELR/ALR Retractor Lock Mode
Amaya passenger seat belts are equipped with
switchable ELR/ALR retractor lock mode:
l Emergency Locking Retractor (ELR) mode:
Allows the seat belt to extend and retract to
allow passengers some freedom of
movement in the seat. Locks only when the
vehicle or occupant slows quickly/abruptly or
stops suddenly. Will not secure a child safety
seat.
l Automatic Locking Retractor (ALR) mode:
Locks and maintains a fixed seat belt (lap
belt) length during use. The belt cannot be
extended further. For use with a child safety
seat.
CHILD RESTRAINT SYSTEMS
Occupants under 40” height must use Child Seat /
Booster
The seat belts are equipped with switchable
ELR/ALR retractor lock mode.
Activate the ALR retractor lock mode to hold a
child restraint system by pulling the shoulder belt
all the way out. Allow it to retract to desired length.
Check that the belt straps are fully tightened and
the retractor / webbing is locked.
Note: Unbuckling the belt and allowing it to retract
fully deactivates the ALR retractor
Failure to use the ALR lock mode will result in the
child safety seat not being properly secured.
When using a booster seat, do not pull the shoulder
belt all the way out. Doing so would engage the
ALR lock mode which is not recommended with
booster seat.
Install the child seat/booster according to the
manufacturer’s instructions.
FOLDING TRAYS
Two optional folding tray models can be installed in
the coach.
FOLDING TRAY MODELS
NOTE
Both tray models as well as the tray installed onto
each modesty panel are equipped with tumbler
holders.
SWIVEL SEATS
The coach may be equipped with two sets of swivel
seats to allow installation of card tables. The swivel
seat can be rotated for passenger privacy. Follow
this procedure for seat rotation:
1. Loosen completely the threaded stud knob under
the seat on the aisle side.
LOOSEN THE KNOB
2. Pull the seat toward the aisle to unlock the
rotation.
To Next Page
