5-38 Other Features

PA-1628Operator's ManualH3-45 COACH

Platform rises from present height towards vehicle floor; rollstop rises before

platform leaves ground.

STOW / IN Platform retracts into vehicle, or stows.

PLATFORM POSITION WITH INTERMEDIATE HEIGHT (OPTIONAL FEATURE)
