7. Tilt headlight assembly up into its housing
then secure using fixing screw.
NOTE
Make sure headlight assembly is properly
positioned into its housing before securing
using fixing screw.
8. Perform alignment procedure.
NOTE
The headlight aim must be checked and
adjusted even if it was properly adjusted
before the sealed beam unit was replaced.
10.1.5 Front Turn Signal
The front turn signal is part of the front headlight
assembly. The turn signal is a sealed unit (LED)
located on each front corner and should be
replaced as an assembly. Turn signal is visible
from both front and side.
Removal and Replacement
1. Pull the release handle located inside the
front service compartment to tilt down the
entire bumper assembly.
2. Remove the headlight screw fixing the
headlight assembly, then tilt headlight
assembly down (Fig. 27 and 29).
3. Partially unfasten back plate fixing screws,
then remove signal lamp.
4. Remove socket from signal lamp.
5. Install wiring connector on back of new
signal lamp then install signal lamp.
6. Fasten back plate fixing screws then tilt
headlight assembly up into its housing then
secure using fixing screw.
NOTE
Make sure headlight assembly is properly
positioned into its housing before securing
using fixing screw.
10.2 STOP, TAIL, DIRECTIONAL, BACK-UP,
AND HAZARD WARNING LIGHTS
A combination stoplight, taillight, directional
signal light and back-up light assembly is
mounted at the rear, on each side of the vehicle.
Furthermore, when braking, two center
stoplights (LED) and a center high-mounted stop
light (CHSL) (LED) will illuminate simultaneously
with the stoplights on the sides for increased
safety. The L.H. and R.H. side center stop lights
are also used as directional signal and marker
lights.
The stop, tail, directional signal and back-up
lights consist of individual LED lights mounted
on the engine rear door, and each light is
serviced individually as a complete unit. The
back-up light uses a regular tungsten bulb.
The hazard warning flashing system uses the
front, side and rear directional lights
simultaneously. This system is energized by a
switch on the L.H. dashboard.
10.2.1 Lamp Removal and Replacement
1. Open engine compartment rear door.
2. Remove the lamp support retaining screws
(2), and then from the outside, remove the
lamp and its support.
3. From the outside, install the new lamp with
its support then fasten the retaining screws.
10.2.2 Center Stoplights and Center High-
mounted Stop Light (CHSL) Removal
and Replacement
These (LED) lights are sealed unit and should
be replaced as an assembly in accordance with
the following procedure:
1. Unscrew both “Phillips” light screws then
remove the light assembly.
2. Install new light assembly and secure using
screws.
10.3 LICENSE PLATE LIGHT
Two LED units are mounted above the rear
license plate(s) of vehicle. In case of burn out,
the LED unit must be changed according to the
following procedure.
1. Pry out the rubber seal with a small
screwdriver. Pull on the LED unit and
disconnect it.
2. Reconnect new LED unit, place rubber seal,
and press on it until it is seated in position.
10.4 CLEARANCE, IDENTIFICATION AND
MARKER LIGHTS
The vehicle is equipped with marker,
identification and clearance lights (LED). The
clearance lights are mounted at each corner of
the coach near the top and the identification
lights are in the upper center of rear and front
sections.
