Section 16: SUSPENSION
PA1593
8
CAUTION
It is extremely important upon reconnection of
the rods that the proper clearance height
between the axle and body be maintained.
Otherwise, the rubber bushings in radius rod
ends will become preloaded, thus reducing
their life span.
2.4 SWAY BAR
A sway bar is provided on the front axle to increase vehicle stability. It controls lateral motion (swaying
movement) of the vehicle (Fig. 10).
FIGURE 10: I-BEAM FRONT AXLE SWAY BAR 16099
2.4.1 Removal
1. Disconnect the two links from sway bar.
2. Safely support the sway bar. Unbolt the four
bushing collars from subframe.
3. Remove sway bar.
NOTE
Sway bar bushings are slitted to ease their
removal.
2.4.2 Installation
1. Loosely install the sway bar.
2. Tighten the eight bushing collar nuts to
appropriate torque (see Torque Table 1).
3. Install two sway bar link upper and lower
nuts and tighten to appropriate torque (see
Torque Table 1).
4. Install a cotter pin on each nut and bend.
