Section 11: REAR AXLES
PA1593
5
The drive axle alignment consists in aligning the
axle according to the frame. The axle must be
perpendicular to the frame. The alignment is
achieved with the use of shims inserted between
the lower longitudinal radius rod supports and
the frame.
Drive axle alignment is factory set and is not
subject to any change, except if the vehicle has
been damaged by an accident or if there are
requirements for replacement.
If the axle has been removed for repairs or
servicing and if all the parts are reinstalled
exactly in the same place, the axle alignment is
not necessary. However, if the suspension
supports have been replaced or altered,
proceed with the following instructions to verify
or adjust the drive axle alignment.
NOTE
When drive axle alignment is modified, tag
axle alignment must be re-verified.
1.10.1 Procedure
1. Park vehicle on a level surface, then chock
front vehicle wheels.
2. Using two jacking points (which are at least
30 inches [76 cm] apart) on drive axle, raise
the vehicle sufficiently so that wheels can
turn freely at about ½ inch from ground.
Secure in this position with safety stands,
and release parking brake.
3. Install wheel mount sensors on front end
and drive axle wheels (fig. 6).
NOTE
See reference numbers on wheel mount
sensors (fig.7).
NOTE
Select axle specifications in the appropriate
chart.
DRIVE AXLE ALIGNMENT
With the system installed as in figure 7, adjust drive axle according to specifications' chart below.
DRIVE AXLE
ALL VEHICLES
Alignment / value Minimum value Nominal value Maximum value
Thrust angle (deg.) -0.04 0 0.04
Total Toe (deg.) 0.18 Toe-in 0 0.18 Toe-out
TAG AXLE ALIGNMENT
Remove and reinstall all wheel mount sensors on the drive and tag axles (fig. 7);
NOTE
For an accurate alignment, the tag axle must be aligned with the drive axle.
NOTE
Reinstall wheel mount sensors as shown in figure 7.
Adjust tag axle according to specifications' chart below in reference with drive axle.
