Section 00: GENERAL INFORMATION
PA1593
10
TYPE
DESCRIPTION
THREAD
GRADE
RECOMMENDED
TORQUE
lbf-ft (dry) otherwise
specified
Tolerance: ±10%
SAE 5/8-18 unf 8 240
SAE 3/4-10 unc 5 266
SAE 3/4-10 unc 8 376
SAE 3/4-16 unf 5 298
SAE 3/4-16 unf 8 420
SAE 7/8-9 unc 5 430
SAE 7/8-9 unc 8 607
SAE 7/8-14 unf 5 470
SAE 7/8-14 unf 8 670
METRIC M6 X 1 nut 9 / screw 8.8 7
METRIC M6 X 1 nut 10 / screw 10.9 9
METRIC M8 X 1.25 nut 9 / screw 8.8 16
METRIC M8 X 1.25 nut 10 / screw 10.9 22
METRIC M10 X 1.5 nut 9 / screw 8.8 32
METRIC M10 X 1.5 nut 10 / screw 10.9 43
METRIC M12 X 1.75 nut 9 / screw 8.8 60
METRIC M12 X 1.75 nut 10 / screw 10.9 74
METRIC M14 X 2 nut 9 / screw 8.8 90
METRIC M14 X 2 nut 10 / screw 10.9 120
METRIC M16 X 2 nut 9 / screw 8.8 140
METRIC M16 X 2 nut 10 / screw 10.9 190
METRIC M16 X 1.5 nut 10 / screw 10.9 230
METRIC M20 X 2.5 nut 9 / screw 8.8 275
METRIC M20 X 2.5 nut 10 / screw 10.9 450
METRIC M20 X 1.5 nut 10 / screw 10.9 465
METRIC M22 X 2.5 nut 9 / screw 8.8 345
METRIC M22 X 2.5 nut 10 / screw 10.9 493
METRIC M24 X 3 nut 9 / screw 8.8 475
METRIC M24 X 3 nut 10 / screw 10.9 640
