PREVOST X3-45 2016

To Next Page

To Previous Page

PROCEDURE NO: PR060041 REVISION 01

Page 5 of 7

Disconnect 3 connectors from VECU

Disconnect 3 connectors from CECM

Disconnect connector A 83 under Volvo Link

module
