PROCEDURE NO: PR060041 REVISION 01
Page 7 of 7
2.50
Location: Evaporator Compartment
Disconnect A 54 module located inside the
evaporator compartment, on the door.
2.60 When all the previous steps are done, you can do
welding on the vehicle.
ENSURE THAT THE WELDING GROUND
RETURN CLAMP IS WELL SECURED AND
MAKES A GOOD ELECTRICAL CONTACT
WITH A LARGE METALLIC AREA OF THE
CHASSIS LOCATED NEAR THE WELDING
POINT AS MUCH AS POSSIBLE.
2.70
When welding is completed, reconnect all the
modules.
Make sure that the connectors locking tab are well
engaged!
BE CAREFUL TO MAKE THE PROPER
CONNECTIONS, IF NOT, SOME SYSTEMS
OR COMPONENTS MAY NOT BE USABLE.
