Chapter 4 ANSI Emulation
182
Pos. on BC/OvrSz
• Set to top. The paper is fed back to the top of barcodes or
oversized characters after they are printed. This allows printing
on the same line.
• Set to bottom. The printer will continue printing without
backing up.
BC Check Digit
• By host. The host calculates the barcode check digit and
sends it along with the barcode. The check digit is not verified
by the printer, but printed as it was received.
• By printer. The barcode is sent without the check digit, and the
printer calculates and adds it in.
Barcode Darkmode
• Enable. The barcodes are printed at a higher resolution.
• Disable. The barcodes are printed at lower resolution but at a
higher speed.
PUM Default
This is the Unit Of Measure (UOM) as it is used within the ANSI
emulation. Coordinates received in ESC sequences can be sent in
two UOM’s: Decipoints, which is a unit of 1/720 inch, or in lines or
columns using the current LPI and CPI values. The UOM used is
determined by this configuration setting.
Truncate PI Slew
• Truncate At TOF. The slew is terminated when the next Top-of-
Form is reached. (This function applies to the ANSI EVFU
only.)
• Disable. PI slews will be completed independent of their
length.
