Chapter 4 HOST INTERFACE
200
Latch Data On
Specifies whether the data is read on the leading or trailing edge of
the data strobe signal.
Prime Signal
• Enable. The parallel port will perform a warm start (reboot) if
the host asserts the Prime Signal.
• Disable. The parallel port will not perform a warm start (reboot)
if the host asserts the Prime Signal.
TOF Action
• Reset. A form feed is performed before a warm start when the
prime signal is asserted from the host. This setting is used only
if the Prime Signal parameter is enabled.
• Do Nothing. Nothing occurs before a warm start when the
prime signal is asserted from the host.
Buffer Size in K
Configures the amount of memory allocated for the Centronics
parallel port buffer. You can specify between 1 and 16 Kbytes, in 1-
Kbyte increments.
