Chapter 4 Configuration Overview
88
Brief descriptions follow for the first-level configuration menu
options:
• CONFIG. CONTROL — These options allow you to save, print,
load, delete, name, and reset entire sets of configuration
parameters.
• ACTIVE IGP EMUL — This menu allows you to select the PGL
or VGL emulation from the menu if IGP is installed.
• EMULATION — This menu allows you to configure the options
which are available for the current operating (active) emulation.
For example, if LinePrinter+ is the active emulation, then the
LinePrinter+ emulation options can be configured using this
menu.
• MAINT / MISC — These options provide miscellaneous
functions, such as printing a hex dump, selecting a display
language, setting the lock key, and choosing whether the
printer will power up in offline or online mode.
• HOST INTERFACE — These options allow you to select either
the Serial RS-232, Serial RS-422, Centronics
®
parallel,
Dataproducts
®
parallel and Long Lines, Ethernet
™
, IEEE
®
1284 parallel, Auto Switching, Coax or Twinax interface for the
printer (which must match the interface cabling you installed
while setting up your printer, described in Chapter 2). This
menu also allows you to configure several parameters for each
interface.
• ETHERNET PARAMS — This option allows you to view and
change the IP Address, Gateway Address, and Subnet Mask.
The MAC Address may also be viewed.
• PRINTER CONTROL — These options allow you to select
several operating parameters for the printer, such as the speed
at which paper will advance when slewing.
• DIAGNOSTICS — These options include the diagnostic tests,
system memory, and statistics of the printer.
• RIBBONMINDER — The options in this submenu allow you to
enable the RibbonMinder
™
feature and set its parameters.
