Chapter 7 Diagnosing Problems
H01: PCI J12
See User Manual
No The controller board is
not communicating with
the PCI card in PCI slot
J12. This could indicate a
bad PCI card, poor
connection, or problem in
the PCI bus.
Contact your authorized service
representative.
1
H02: PCI J13
See User Manual
No The controller board is
not communicating with
the PCI card in PCI slot
J13. This could indicate a
bad PCI card, poor
connection, or problem in
the PCI bus.
Contact your authorized service
representative.
1
<Online, etc...>
Half Speed Mode
No Status message: The
controller samples the
operating temperature of
key components of the
print mechanism. When
higher than normal
temperatures are sensed,
the print speed is
automatically reduced by
50% and the message
sent the LCD. When the
components cool down,
the print speed returns to
100% and the message
clears.
No action is required. If the
message appears often, contact
your authorized service
representative.
1
HAM. COIL OPEN* No Hammer Coil Open.
Electrical malfunction of
one or more hammer
coils.
Contact your authorized service
representative.
1
HAMMER COIL BAD*
#, #, #, ...etc
No Hammer coil # failed
current test at power up.
Contact your authorized service
representative.
1
HAMMER SHORT*
See User Manual
No Electrical malfunction of
one or more hammer
coils.
Contact your authorized service
representative.
1
HB NOT INSTALLD* No Hammer Bank Not
Installed. Self-test
routines do not detect
hammer coils at printer
start-up.
Contact your authorized service
representative.
1
Table 15. LCD Message Troubleshooting Table
Displayed Message
Can User
Correct?
Explanation Solution
To Next Page
