Connections - universal input
universal inputUI
common neutral for inputFG (Field ground)
Connections - analogue output
analogue outputAO
common neutral for outputFG (Field ground)
Connections - relay output
common contactCOM
normally open contact, open when output is not poweredNO (normally open)
normally closed contact, closed when output is not poweredNC (normally closed)
Points to be considered
The use of mains wiring is not permitted in the Compass cabinet.
