USER’S MANUAL. PRODIG-5
11/2006 Page 31
English
Band Powering voltages
SATELLITE
External
5 V
13 V
15 V
18 V
24 V
13 V + 22 kHz
18 V + 22 kHz
TERRESTRIAL
MATV
External
5 V
13 V
15 V
18 V
24 V
Table 3.- External units powering voltages.
In the External power supply mode is the unit powering the amplifiers before the
antenna (terrestrial television) or the satellite TV receiver (house-hold or community)
also powers the external units.
The DRAIN [3] indicator lights when current is flowing to the external unit. If any
kind of problem occurs (e.g., a short circuit), an error message appears on the monitor
('SUPPLY SHORT'), the acoustic indicator will be heard and the instrument will cease
to supply power. The PRODIG-5
(EXPLORER) does not return to its normal operating
state until the problem has been solved, during this time it verifies every three seconds
the persistence of the problem warning with an acoustic signal.
5.8 Automatic signal identification function (AUTO ID)
The PRODIG-5 (
EXPLORER) allows automatically identifying TV signals,
according to the established configuration, which are presents in the channel or tuned
frequency. In order to activate this function must once press
[25] key. Specially
useful, is to combine this process with the spectrum monitoring
[13], so that after
locating the marker on the levels susceptible to contain a transmission, and activating
later the process of automatic identification in order to identify the present signal.
