USER’S MANUAL. PRODIG-5
Page 4 11/2006
1.2 Specifications
CONFIGURATION FOR MEASURING LEVEL AND POWER
TUNING Digital frequency synthesis. Continuous tuning from
45 to 865 MHz and from 950 to 2150 MHz
Tuning modes Chanel or frequency (IF or downlink at satellite
band).
Channel plan configurable on demand
Resolution 45-865 MHz: 50 kHz
950-2150 MHz: < 200 kHz (span FULL-500-200-
100-50-32-16 MHz).
Automatic search (Explorer) Threshold level selectable. DVB-T or DVB-C
selection
Signal identification Analogue and digital. Automatic.
RF INPUT
Impedance 75 Ω
Connector Universal, with BNC or F adapter.
Maximum signal 130 dBµV
Maximum input voltage
DC to 100 Hz 50 Vrms (powered by the AL-103 power charger)
30 Vrms (not powered by the AL-103 power
charger)
45 MHz to 2150 MHz 130 dBµV
DIGITAL SIGNALS MEASUREMENT
POWER RANGE
COFDM: 45 dBµV to 100 dBµV.
QAM: 45 dBµV to 110 dBµV.
QPSK: 44 dBµV to 114 dBµV.
MEASUREMENTS
DVB-T (COFDM): Power, CBER, VBER, MER, C/N
Presentation: Numeric and level bar.
DVB-C (QAM): Power, BER, MER, C/N
Presentation: Numeric and level bar.
DVB-S (QPSK): Power, CBER, VBER, MER, C/N
Presentation: Numeric and level bar.
