USER’S MANUAL. PRODIG-5
Page 44 11/2006
IMPORTANT REMARK
DVB channels tuning may require an adjusting process. It is recommended to follow
next procedure:
1. From the spectrum analyser mode
[13], tune the channel at its central
frequency.
2. Switch to Measurements mode
[12], measurement selection.
3. If in the lower line of the screen does not appear MPEG-2 message (and
consequently BER is unacceptable), by turning the rotary selector deviate the
tuning frequency until MPEG-2 message appears. Finally tune channel again to
minimize the frequency deviation which optimizes the BER and therefore
minimize the BER.
If it is not possible to detect any MPEG-2 channel, make sure that digital signal
parameters are correctly defined.
5.14 Selecting the Measurements
The types of measurements available depend on the operating band (terrestrial or
satellite) and the type of signals (analogue or digital).
Terrestrial band - Analogue channels:
Level Level measurement of the currently tuned carrier.
Video / Audio Video carrier to audio carrier ratio.
C/N Ratio between the modulated signal power and the equivalent
noise power for a same bandwidth.
Terrestrial band - Digital channels (DVB-C and DVB-T):
Channel power Channel power is measured assuming that power spectral
density is uniform throughout channel bandwidth.
To measure it correctly it is indispensable to define the
Channel BW.
To Next Page
