USER’S MANUAL. PRODIG-5
11/2006 Page 13
English
3 INSTALLATION
3.1 Power Supply
The PRODIG-5 (
EXPLORER) is a portable instrument powered by one 7.2 V - 11
Ah Li-Ion battery. There is also an external DC charger provided for mains connection
and battery charging.
3.1.1 Operation using the External DC Charger
Connect the external DC charger to EXT. SUPPLY [32] on the PRODIG-5
(EXPLORER) side panel. Connect the DC charger to the mains. Then, press the rotary
selector [1] for more than two seconds. The level meter is now in operation and the
battery is slowly charged. When the instrument is connected to the mains, the
CHARGER indicator [4] remains lit. This indicator changes of colour according to the
battery charge status:
BATTERY CHARGE STATUS
OFF ON
RED
< 50 % < 90 %
YELLOW
> 50 % > 90 %
GREEN
100 % 100 %
Table 1.- Indication of the battery charge status (CHARGER).
3.1.2 Operation using the Battery
For the device to operate on the battery, disconnect the power cable and press
the rotary selector [1] for more than two seconds. The fully charged battery can power
the equipment for more than 3.5 hours non-stop.
If battery is very weak, the battery cut-off circuit will prevent the device from
functioning. In such a situation battery must be recharged immediately.
Before taking any measurements, you have to check the charge status of the
battery by checking the battery charge level indicator that appears when activating the
measurement mode pressing key
[12]. These are the indicators on screen:
