USER’S MANUAL. PRODIG-5
11/2006 Page 33
English
Whenever a new process of exploration is activated, the PRODIG-5 analyses all
the present channels in the active channel plan, which acts as pattern channel plan
specified by means of the option CHANNEL SET from configuration measurement
menu: CONFIGURATION
[17].
If during exploration or automatic identification process the
EXPLORER detects
new parameters for some channel or frequency a new list will be generated with the
information updated and will be saved with the name of the original channel plan
followed by the extension: _0x. (See the following Figure).
Figure 10.- New channel plan generation process.
The user can delete any channel list, or remove and add channels from another
standard list by means of the editing options offered by the
UTILITIES [22] menu.
The
EXPLORER allows directly changing the tuned channel pertaining to the active
channel plan by means of the horizontal
cursors [6]. From this way, once selected
the channel tuning field
[24] and in the TV [10] and MEASUREMENTS
[12] operation modes is possible to check cyclically the entire active channel list.
