USER’S MANUAL. PRODIG-5
Page 36 11/2006
FREQ:
CH:
READY TO START
48.30
- - -
MHz
kHz
REF:
LEVEL:
- - -
- - -
dBuV
dBuV
DATALOGGER_01
POINT_01
ATTENUATION TEST
START EXIT
TEST POINT:
CHANNEL SET:
Figure 13.- Datalogger screen for Attenuation test frequencies.
Once the START option is selected the instrument will capture all test values
corresponding to the three pilot frequencies in the active band. When measuring is
completed, it will offer the options to store data or to start a new acquisition.
FREQ:
CH: PILOT_01
48.30
- - - -
MHz
kHz
REF:
LEVEL:
90.6
86.3
dBuV
dBuV
SAVE
DATALOGGER_01
POINT_01
ATTENUATION TEST
FINISHED
TEST POINT:
CHANNEL SET:
START EXIT
Figure 14.- End of data acquisition.
NOTE: In order to select the function (Attenuation test or IF SAT test) might be
necessary to switch the frequency band between Terrestrial or Satellite by
means of the front panel
key [10].
