12.4.2.1.5 Inputs
A 0/1 contact signal, for example at pin 1 of the
‘Config I/O’
terminal can
be a triggering event.
Time events (triggers) Action
Config I/O 1 Relay 2 open
The example means:
If an 0/1 contact signal is closed between Pin 1 of the
‘Config I/O’
con‐
nector and Pin 4, then the
‘Relay 2’
should switch to
‘open’
status.
Example
12.4.2.1.6 Outputs
The timer can output a 1/0 contact signal e.g. between pin 3 of the
‘Config
I/O’
connector and pin 4.
Time events (triggers) Action
Cycle Switching time
workdays 1 (Mo-Fr) Time of day 12:00 Config I/O 3
The example means:
At 12:00 on workdays, the timer outputs a 1/0 contact signal e.g.
between pin 3 of the
‘Config I/O’
connector and pin 4
Example
12.4.2.2 1 time event - several actions
You can assign 1 time event to several actions. To do so, always use the
same cycle and the same switching time! :
No. Time event (trigger) Action
01 workdays 1 (Mo-Fr) Time of day
12:00
Stop -
02 workdays 1 (Mo-Fr) Time of day
12:00
Batch (input) 500 ml
03 workdays 1 (Mo-Fr) Time of day
12:00
Relay 1 -closed
04 - - ... .
Example
–
For details on the sorting sequence of the program
lines see Ä ‘Sorting sequence’ on page 67.
–
The timer program can have a maximum of 99 pro‐
gram lines.
Set up /
‘Menu’
66
